DAMP PROOF SLIM VALUE
DP SLIM VALUE 1200 36 W 4000 K IP65 GY

GTIN: 4058075066458
Folding box / 1
Show all packages
Our warranty conditions
PRODUCT DETAILS
Product benefits
- Uniform light distribution
- Energy savings of up to 50 % (compared to luminaires that use fluorescent lamps)
- Very slim housing
- Easy installation as mounting brackets can be positioned freely on the luminaire
- Tool-free electrical connection due to push button connector
- 3 years guarantee
- Easy access to electrical terminal thanks end caps with clip mechanism
Areas of application
- Industrial and storage facilities
- Car parks and underpasses
- Garages
- Workshops, assembly lines
Product features
- High luminous efficacy: up to 110 lm/W
- Beam angle: 120°
- Type of protection: IP65
Equipment / Accessories
- Stainless steel clamps with safety screws included
- Mounting accessories included (suspension kit, theft protection kit)
Safety advice
- All electrical connections must be made by a qualified person.
- Caution, risk of electric shock.
References / Links
- For Guarantee see www.ledvance.com/guarantee
Electrical data
Nominal wattage | 36.00 W |
Nominal voltage | 220…240 V |
Mains frequency | 50…60 Hz |
Nominal current | 200 mA |
Inrush current | 7 A |
Inrush current time Th50 | 60 µs |
Max. number of luminaires per miniature circuit breaker B16 | 77 |
Max. number of luminaires per miniature circuit breaker C10 | 48 |
Max. number of luminaires per miniature circuit breaker C16 | 77 |
Power factor λ | ≥0.90 |
Protection class | II |
Operating mode | Integrated LED driver |
Photometrical data
Luminous flux | 4000 lm |
Luminous efficacy | 110 lm/W |
Color temperature | 4000 K |
Light color (designation) | Cool White |
Color rendering index Ra | > 80 |
Standard deviation of color matching | ≤5 sdcm |
Photobiological safety group acc. to EN62778 | RG0 |
Beam angle | 120 ° |
Dimensions & Weight
Length | 1200.00 mm |
Height | 48.00 mm |
Width | 35.00 mm |
Product weight | 450.00 g |
Materials & Colors
Product color | White |
Housing color | White |
Body material | Polycarbonate (PC) |
Cover material | Polycarbonate (PC) |
Light emitting surface material | Polycarbonate (PC) |
Glow Wire Test according to IEC 60695-2-12 | 650 °C |
Mercury content | 0.0 mg |
Application & Mounting
Ambient temperature range | -20…+40 °C |
Temperature range at storage | -30…+70 °C |
Type of connection | Screwless terminal, 2-Pole |
Type of protection | IP65 |
Protection class IK (shock resistance) | IK08 |
Dimmable | No |
Mounting type | Suspended/Surface |
Mounting location | Ceiling |
Application environment | Indoor |
Lifespan
Lifespan L70/B50 at 25 °C | 30000 h 1) |
Lifespan L80/B10 at 25 °C | 27000 h 1) |
Lifespan L90/B10 at 25 °C | 19000 h |
Number of switching cycles | 100000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
Control gear
Output current | 460 mA |
Certificates & Standards
Standards | CE, CB |
Luminaire with limited surface temperature, "D sign" | Yes |
Ball shot safe | No |
Replaceable light source (EPREL) | Not replaceable |
PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS
Quantity of precious metals | Contains at least 10 mg |
Quantity of rare earths | Contains at least 1 mg |
Minimum rate of recycled material in packaging | 80 % 1) |
Minimum percentage of recycled content in the product | 0 % 1) |
Product recyclability | Mostly recyclable product 1) |
Packaging recyclability | Mostly recyclable packaging 1) |
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
---|---|---|---|---|
4058075066458 | Folding box 1 |
39 mm x 1,257 mm x 50 mm | 533.00 g | 2.45 dm³ |
4058075066465 | Shipping box 20 |
1,271 mm x 215 mm x 226 mm | 13700.00 g | 61.76 dm³ |

User instruction / safety instructions
UI DP SLIM VALUE IP65
UI DP SLIM VALUE IP65

Legal information
LS Insert DP Slim Value IP65
LS Insert DP Slim Value IP65

Legal information
Informationstext 18 Abs 4 ElektroG
Informationstext 18 Abs 4 ElektroG

Declarations of conformity
EC Declaration of Damp Proof SlimValue
EC Declaration of Damp Proof SlimValue

Declarations of conformity
Attestation-of-Conform ity DP Slim Value DEKRA
Attestation-of-Conform ity DP Slim Value DEKRA

Product image: white background, horizontal
Dampproof Slim Value 1200 36W IP65
Dampproof Slim Value 1200 36W IP65

Product image: white background, upright
Dampproof Slim Value 1200 36W IP65
Dampproof Slim Value 1200 36W IP65
Product line drawing with letters
Dampproof Slim Value 1200 36W IP65
Dampproof Slim Value 1200 36W IP65
Product line drawing with numbers
Dampproof Slim Value 1200 36W IP65
Dampproof Slim Value 1200 36W IP65

Combo Shot = Product Beauty Shot + Packaging Image
DP SLIM VALUE 1200 36W 4000K IP65
DP SLIM VALUE 1200 36W 4000K IP65

Packaging image, frontal
DP SLIM VALUE 1200 36W 4000K IP65
DP SLIM VALUE 1200 36W 4000K IP65

Packaging image, spacial
DampProof VALUE 1200 IP65 36W 840 MiCh Side2
DampProof VALUE 1200 IP65 36W 840 MiCh Side2

IES file (IES)
DP SlimValue 1200 36W 4000K IP65
DP SlimValue 1200 36W 4000K IP65

LDT file (Eulumdat)
DP SlimValue 1200 36W 4000K IP65
DP SlimValue 1200 36W 4000K IP65

ULD file (DIALux)
DAMPPROOFSLIMVALUE1200 36W4000KIP65GY
DAMPPROOFSLIMVALUE1200 36W4000KIP65GY

ROLF file (RELUX)
DP SLIMVALUE 1200 4000K
DP SLIMVALUE 1200 4000K

UGR file (UGR table)
4058075066458 DP SlimValue 1200 36W 4000K IP65
4058075066458 DP SlimValue 1200 36W 4000K IP65
Light distribution curve type cone
4058075066458 DP SlimValue 1200 36W 4000K IP65
4058075066458 DP SlimValue 1200 36W 4000K IP65
Light distribution curve type polar
4058075066458 DP SlimValue 1200 36W 4000K IP65
4058075066458 DP SlimValue 1200 36W 4000K IP65

BIM Revit 3D
Damp Proof Slim Value
Damp Proof Slim Value

CAD STEP 3D
DP SLIM 1200
DP SLIM 1200

Tender documents
DAMP PROOF SLIM VALUE 1200 36 W 4000 K IP65 GY-EN
DAMP PROOF SLIM VALUE 1200 36 W 4000 K IP65 GY-EN

Application pictures
Mokpol Warsaw Poland
Mokpol Warsaw Poland

Application pictures
Mokpol Warsaw Poland
Mokpol Warsaw Poland

Application pictures
Mokpol Warsaw Poland
Mokpol Warsaw Poland

Application pictures
Mokpol Warsaw Poland
Mokpol Warsaw Poland
EAN | SEG number | STK number | EFO number |
---|---|---|---|
4058075066458 | 7214024 | 4315512 | 3241098 |
